Description
Programmable 98% RH -50℃ Vibration Temperature Humidity Chamber mainly the synthesis of the test chamber and the vibration test system. During the test, the temperature, humidity, vibration (high or low temperature) and electrical stress are applied to the sample in the same climate test chamber according to the specified period. The "environmental simulation" test of temperature, humidity and vibration is carried out.
Compared with a single environmental factor, it more truly simulates the transportation and actual use environment of the product, and fully considers the requirements of different working conditions in the design. Temperature humidity vibration combined test chamber is an important test link in the process of new product research and development, reliability test, identification test, stress screening test, batch production, etc.
Main Parameter
| Name | Programmable 98% RH -50℃ Vibration Temperature Humidity Chamber |
| Model | THV-1000 |
| Internal Dimension (mm) | 1000*1000*1000 |
| Overall Dimension (mm) | 1800*4600*2600 |
| Temperature Range | -50℃ ~ +150℃ |
| Temperature Fluctuation | ± 0.5 ℃ |
| Temperature Deviation | ± 2.0 ℃ |
| Cooling Rate | 5℃ / min |
| Heating Rate | 5℃ / min |
| Humidity Range | 30% ~ 98% RH |
| Humidity Deviation | ± 2.5% RH |
| Controller | Programmable color LCD touch screen controller Ethernet connection, PC Link |
| Dynamic diameter | ￠240mm |
| Blower | 4Kw blower, including muffler. |
| Max load | 500kgs |
| Cooling system | Mechanical compression refrigeration system |
| Refrigerating unit | French TECUMSEH compressor |
| Refrigerant | R404A, R23 |
| Heating Element | Nichrome heater |
| Controller | Programmable color LCD touch screen controller,Ethernet connection, PC Link |
| Interior Material | SUS304 stainless steel |
| Power Supply | 380V 50Hz |
Main Details
|
|
|
| Rail and Lift Support Combining a rail support for horizontal move and a lift support for vertical move. | Blower Constant temperature humidity and vibration chamber equip 4Kw blower, including muffler. |
Advantage
1. Temperature humidity vibration chamber equip double refrigerat ion system, superior refrigeration performance,
2. Independent vibration control system, constant temperature and humidity control system
3. Individual test or compound test for high temperature, low temperature, constant temperature and humidity, vibration
4. vibration test chamber with mobile track design, it is easy to operate compound test or individual function test
5. Large-screen color touch control screen, independent control cabinet
6. The design of the detachable bottom plate of the test box can be connected with various electric vibration tables.
7. Multi-layer observation of heat insulation treatment, wide field of vision
Warranty & Service
Temperature humidity vibration chamber and all LIB INDUSTRY test machine support one stop service
1. 3 Years Warranty, Lifelong Follow-up Services
2. Professional After-sales Team
3. If you have any questions during operation,
4. we will supply solution to you with 24 hours.
